HONDA WB30XD Water Pump set

Model WB30XD

Overview

Honda WB30XD Water Pump set is a high-performance 3-inch petrol-operated water pump set designed for high-volume water transfer, agricultural irrigation, dewatering and general water management applications.

Detailed Description

Honda WB30XD Water Pump set is a high-performance 3-inch petrol-operated water pump set designed for high-volume water transfer, agricultural irrigation, dewatering and general water management applications. Powered by a Honda GX160D 163 cc 4-stroke OHV petrol engine, the WB30XD delivers a maximum water discharge of up to 1,100 liters per minute with a total head of 23 meters.

The pump features an 80 mm (3-inch) suction port and 80 mm (3-inch) discharge port. Its centrifugal self-priming design enables convenient operation, while the monoblock horizontal construction with mechanical seal provides dependable performance. The 3.1-litre fuel tank, recoil starting system and lightweight 26 kg construction make the pump convenient for field and professional use.

The Honda WB30XD is particularly suitable for farmers, contractors and professionals requiring high-volume water pumping for irrigation, construction dewatering, drainage and general water-transfer applications.

Key Highlights:

Honda GX160D 163 cc petrol engine
3-inch water pump
Maximum discharge: 1,100 L/min
Total head: 23 meters
Suction head: 7.5 metres
80 mm suction and discharge ports
Centrifugal self-priming pump
3.6 kW net engine power @ 3,600 RPM
3.1 L fuel tank
Recoil starting system
Dual-type air cleaner
Mechanical seal
Full protective frame
Lightweight and portable construction
Suitable for irrigation, dewatering and water transfer

Warranty Default By Manufacturer

Delivery Pan India

Support During Office Hours

Get Best Quote

Submit your requirement & get custom pricing.

Request Quote

Technical Specifications

Specification	Honda WB30XD
Model	WB30XD
Pump Type	Centrifugal, Self-Priming
Pump Construction	Monoblock Horizontal with Mechanical Seal
Pump Size	3 inch
Suction Port	80 mm / 3 inch
Discharge Port	80 mm / 3 inch
Maximum Discharge	1,100 L/min
Total Head	23 m
Suction Head	7.5 m
Engine Model	Honda GX160D
Engine Type	4-Stroke, Single-Cylinder, OHV, Air-Cooled
Displacement	163 cc
Bore × Stroke	68 × 45 mm
Net Power	3.6 kW @ 3,600 RPM
Rated Power	2.9 kW @ 3,600 RPM
Maximum Torque	11 Nm @ 2,500 RPM
Fuel	Unleaded Petrol
Fuel Tank Capacity	3.1 L
Engine Oil Capacity	0.58 L
Starting System	Recoil Starter
Air Cleaner	Dual Type
Cooling System	Forced Air
Dry Weight	26 kg
Operating Weight	31 kg
Dimensions (L × W × H)	510 × 385 × 435 mm
*Specifications may vary depending on the manufacturer and configuration. Kindly reach out to our sales team for specific product’s availability *

Applications & Uses

Agricultural irrigation
Farm and field water supply
Water transfer from ponds, canals and other water bodies
Construction-site dewatering
Road and municipal dewatering
Tank filling
Drainage applications
General-purpose water transfer
Water-intensive crop irrigation
