Concrete Road Paver

Concrete Road Paver 5.5 Meter

Model .

Detailed Description

A concrete road paver machine (also called a slipform paver or concrete paving machine) is a piece of construction equipment used to lay concrete pavement (roads, runways, highways, industrial floors, etc.) with a high degree of precision and efficiency.

Here’s a breakdown of how it works, its types, key features, and some product / market-examples:

What Is a Concrete Road Paver Machine?

Purpose:

Lay down concrete in a continuous process (rather than pouring in small sections).

Create smooth, flat, and uniform concrete surfaces.

Increase productivity and reduce manual labor in road construction.

How It Works:

Concrete is fed into the machine (from a mixer or batching plant).

Inside the machine, there are augers/spreaders to distribute the concrete evenly.

A “strike-off” system (vibrating bars) levels and compacts the concrete.

The machine moves forward (slips) while maintaining the correct profile (thickness, width) — hence “slipform.”

Key Components:

Augers: Spread concrete laterally.

Vibrators / Tamper bars: Consolidate the concrete to remove air and improve strength.

Rails / Guide system: For guiding machine movement (in fixed form pavers).

Hydraulic system: For raising/lowering parts, adjusting widths, operating vibrators.

Power Unit: Diesel engine or electric motor, depending on model.

Warranty Default By Manufacturer

Delivery Pan India

Support During Office Hours

Get Best Quote

Submit your requirement & get custom pricing.

Request Quote

Technical Specifications

Specification	Details
Paving Width	5.5 m
Paving Thickness 200	500 mm
Machine Type	Fixed Form
Concrete Grade	M25
Drive Type	Mechanical
Engine Power	Electric
Working Speed 0.5	8 m/min
Vibration Type	Internal + Surface, Surface Vibrator
Fuel Type	Electric Motor

Applications & Uses

Concrete roads
Highways
Airport runways
Industrial flooring
Warehouse floors
Factory floors
Parking areas
Bridge decks
Concrete pavements
Canal lining
Commercial construction
Infrastructure development projects
***Specifications may vary depending on the manufacturer and configuration. Kindly reach out to our sales team for specific product’s availability ***
